1000 Ton Hydraulic Baler Machine , Heavy Duty Scrap Steel Baler

  • Product Details:
    Place of Origin: china
    Brand Name: HUAKE
    Certification: CE SGS
    Model Number: Y81-1000
    Payment & Shipping Terms:
    Minimum Order Quantity: 1 SET
    Price: 100000-150000USD
    Packaging Details: EXPORT WORTHY PACKAGE
    Delivery Time: 35-40 DAYS
    Payment Terms: L/C, T/T
    Supply Ability: 60 PCS Per Year
Order phone:+86-13003381217
Inquiry

Detail

Model NO.: Y81-10000 HS Code: 84629190
Port: Shanghai, China Shipment: By Bulk Ship
Transport Package: Export Worthy Package Specification: SGS
Trademark: Huake Origin: China
Advantage: High Pressure ,huge Production Rate,very High Efficiency ,saves A Lot Of Man Power Guarantee: 18 Months And Llife Long Service Free Consultancy
High Light: 1000 Ton huake hydraulic baler machine ,  huake Hydraulic Baler Machine ,  1000 Ton huake hydraulic baler machine heavy duty
Product Description

Ce China High Pressure 1000 Tons Per High Density Hydraulic Automatic Heavy Duty Steel Recycling Baler Sale

detailed specs to choose from :

Y81-1000 high density Hydraulic Scrap Steel Baler 1000 tons power / automatic heavy duty baling machine

MAIN PARAMETERS FOR Y81-10000 HYDRAULIC SCRAP METAL BALER MACHINE

1000 TONS POWER

Machine vedio: https://youtu.be/Q0JZ7iJawmY

ITEM PARAMETERS REMARKS
1 MAIN CYLINDER MODEL YG700/500-1150 TRAVEL LENGTH 1150mm 1000*2 TONS POWER
    MAXIMUM THRUST 10000 KN QUANTITY 2
2 SIDE CYLINDER MODEL YG400/310-2750 TRAVEL LENGTH 2750mm

335TONSx3=1005TONS POWER

335x3=

1005 TONS POWER

    MAXIMUM THRUST 3350 KNX3 QUANTITY 3
3



COVER DOOR CYLINDER

MODEL YG280/200-2600 TRAVEL LENGTH 2600mm 160TONSx2=320 TONS POWER
    MAXIMUM THRUST 1600 KNX2 QUANTITY 2
4 DOOR LOCK CYLINDER MODEL YG200/120-70 TRAVEL LENGTH 70mm 100TONS X3=300 TONS POWER
    MAXIMUM THRUST 1000 KNX3 QUANTITY 3
4 PRESS BOX SIZE 3500×3000×1400 mm L×W×H
5 BALE SIZE (700~2500)×700x700MM 700x700MM L×W×H
6 BALE DENSITY ≥2000kg/m3 STEEL
7 HYDRAULIC SYSTEM WORKING PRESSURE ≤25 MPa
8 TOTAL POWER OF MACHINE 225kW
9 SIGNLE CYCLE TIME 180SECONDS EMPTY LOAD
10 POWER SPECFICATION 380 V/3P,50 Hz
11 OPERATION MODE

AUTOMATIC PLC WITH REMOTE CONTROL

GRAPLE TO GET THE BALE OUT


12 MOTOR FOR THE MAIN PUMPS MODEL YX3-225-4 RATED POWER 45KW
    NOMINAL TURNING SPEED 1470 r/min Quantity 5 Sets
13 Hydraulic Pump Model A4V-250 Rated Pressure 31.5MPa


Nominal

Displacement

250 ml/r Quantity 5sets
14 Oil cooler Model B-14 COOLING EFFFECT 32SQURE METERS
    TYPE Finned heat exchanger Quantity 1set
15 oiL TANK SIZE 8000liters (hydraulic7500liters ) Buyer prepare
16 machine size 9792×8796×3185(cover door open 5378)mm L×W×H
17 Floor space 10.6 ×11.5 m
18 MACHINE WEIGHT:

138.5TONS



METAL BALER CHARACTERISTIC

1. The hydraulic driving is adopted for the machine

2. The manual or PLC automatic control operations.

3. Installation does not need the foundation screw

4. Can choose diesel engine drive or motor driv

5. Three out- bag ways: Turn, Side push, front push.

6. The chamber box size and bale size can according to the customer request.

7, Voltage/frequency can according to customer requirement.

8, Can add two sides of knives and teeth on the chamber box

9. Can be equipped with cooler or heater



Watch The Video

Machine vedio: https://youtu.be/Q0JZ7iJawmY

Place of Origin: Jiangsu, China (Mainland)
Brand Name: Huake
Service : the machine are always tested and assembled before shipping,customer only need to follow simple steps to start .Engineers available on phone 24 hours ,unsolvable problem come to fix.
Model Number: Y81F-160QF
Condition: New
Color: User Defined

Packaging & Delivery







Features:
A) Hydraulic drive, manual valve operation or PLC control...
B) Bale-discharging: "turn-out", "push-out", "forward-out" & manual discharging.
C) Options for different force, press box size, bale shape & size
D)Electrical motor, diesel engine or generator for power.

Applications:
Y81 series of hydraulic scrap balers are applied in steel mills, recycling plants, ferrous & non
-ferrous smelting industry to press scrap metal (steel, copper, aluminum, stainless steel, discarded automobiles, etc)
Into acceptable furnace charges in shape of cuboids, cylinders & octagons.
