quick details :
Brand Name: Huake
Service: The machine are always tested and assembled before shipping, customer only need to follow simple steps to start. Engineers available on phone 24 hours, unsolvable problem come to fix.
Model Number: Y81F-125
After-sales Service Provided: Engineers available to service machinery overseas
Color: User Defined

Turn-out bale discharge Series
Model	Nominal Force (kn)	Press Box Size (L*W*H)(mm)	Bale Size (W*H) (mm)	Bale Weight (kg)	Production (T/h)	Power (kw)
Y81F-63	630	1000*600*500	200*200	20~25	0.9~1.1	7.5
Y81F-100	1000	1000*700*550	250*250	45~55	1.1~1.3	11
Y81F-125A	1250	1200*700*600	300*300	60~80	1.2~1.5	15
Y81F-125A1	1250	1200*800*600	300*300	60~80	1.2~1.6	15
Y81F-125A2	1250	1200*900*600	300*300	60~80	1.2~1.6	15
Y81F-125B	1250	1200*700*600	250*250	45~60	1.2~1.5	15
Y81F-125B1	1250	1200*800*600	250*250	45~60	1.2~1.6	15
Y81F-125B2	1250	1200*900*600	250*250	45~60	1.2~1.6	15
Y81F-125AD	1250	1400*800*700	300*300	65~80	1.5~2.0	18.5
Y81F-160	1600	1400*900*700	320*320	80~110	2.2~3.0	22
Y81F-160A	1600	1600*1000*800	400*400	110~150	2.2~3.0	22
Y81F-160B	1600	1600*1200*800	400*400	130~180	2.6~3.9	15*2
Y81F-200	2000	1600*1000*800	400*400	110~150	2.2~3.0	37
Y81F-200A	2000	1600*1200*800	400*400	130~180	2.8~3.9	37
Y81F-200B	2000	1800*1400*800	450*450	130~180	2.8~3.9	37
Y81F-250A	2500	2000*1400*900	500*500	190~280	3.5~5.0	22*2
Y81F-250B	2500	2000*1750*1000	500*500	200~380	4.0~6.5	22*2
Y81F-250BKC	2500	2000*1750*1000	450*450	160~250	3.2~4.5	22*2
Y81F-315	3150	2500*2000*1200	600*600	250~650	4.5~7.0	45*2
Y81F-400	4000	3500*2000*1200	500*600			45*2
Y81F-500	5000	3000*2500*1200	600*700			55*2
Side Push-out bale discharge Series
Model	Nominal Force (kn)	Press Box Size (L*W*H)(mm)	Bale Size(W*H)(mm)	Bale Weight(kg)	Production(T/h)	Power (kw)
Y81T-63	630	1000*600*500	200*200	28~35	0.9~1.1	7.5
Y81T-100	1000	1000*700*550	230*230	42~53	1.2~1.5	11
Y81T-125A	1250	1200*700*600	300*300	65~80	1.2~1.8	15
Y81T-125B	1250	1200*700*600	250*250	50~62	1.2~1.5	15
Y81T-125AD	1250	1400*800*700	300*300			18.5
Y81T-160	1600	1400*900*700	320*320	70~85	1.5~2.2	22
Y81T-160A	1600	1600*1000*800	400*400	110~150	2.0~3.5	22
Y81T-160B	1600	1600*1200*800	400*400	130~180	2.0~4.0	15*2
Y81T-200A	2000	1600*1200*800	450*450	140~190	2.5~4.5	37
Y81T-200B	2000	1800*1400*900	450*450	210~300	3.0~5.0	22*2
Y81T-250A	2500	2000*1400*1000	500*500	230~270	4.0~6.3	22*2
Y81T-250B	2500	2000*1750*1000	500*500	250~280	5.0~6.3	22*2
Y81T-315A	3150	2000*1400*1000	500*500	250~360	4.0~6.5	37*2
Y81T-315B	3150	2000*1750*1000	500*500	260~370	5.0~7.0	37*2
Y81T-400	4000	3000*2000*1200	500*600	250~380	6.0~8.0	45*2
Y81T-500R	5000	2500*1300*800	500*500	300~500	6.0~10.0	22+37
Forward-out bale discharge Series
Model	Nominal Force (kn)	Press Box Size (L*W*H)(mm)	Bale Size (W*H)(mm)	Bale Weight (kg)	Production(T/h)	Power (kw)
Y81Q-100	1000	1100*600*550	600*220	40~60	1.0~1.8	7.5
Y81Q-135A	1350	1400*600*600	600*240	50~75	1.5~2.8	22
Y81Q-135B	1350	1100*600*600	600*240	45~65	1.2~1.7	15
Y81Q-160	1600	1600*800*600	800*280	60~90	2.0~3.0	22
Y81Q-200	2000	1600*800*700	800*280	90~110	2.5~3.5	30
Y81Q-250	2500	1750*900*800	900*350	110~130	4.5~6.0	22*2

Packaging & Delivery

Features:
A) Hydraulic drive, manual valve operation or PLC control...
B) Bale-discharging: "turn-out", "push-out", "forward-out" & manual discharging.
C) Options for different force, press box size, bale shape & size
D)Electrical motor, diesel engine or generator for power.

Applications:
Y81 series of hydraulic scrap balers are applied in steel mills, recycling plants, ferrous & non
-ferrous smelting industry to press scrap metal (steel, copper, aluminum, stainless steel, discarded automobiles, etc)Into acceptable furnace charges in shape of cuboids, cylinders & octagons



1. We have installed the guardboard on the gate to make the machine stronger and wear resistant, and extend the machine service life.

2. We use blades on the door sizes and feed box sides. The blade can cur extra scrap when machine working better to protect the machine.

3. We use high pressure soft oil pipe,which has better stability ,and anti- vibration protection.

4. Our machine has buffer technology to reduce the impact on machine parts.



Question and answers:

Q:Can I add my logo on the machines?

A: Yes,OEM and ODM are available for us.

But you should send us the Trademark authorization letter.

2. Q:How can i get the after-service?

A: We will send you the spare parts by free if the problems caused by us.

If it is the men-made problems,we also send the spare parts,but you should pay.

3. Q:Do you have inspection procedures for machines?

A:100% self-inspection before packing

4. Q:Can I have a visit to your factory before the order?

A:Sure,welcome to visit our factory.
Here is our factory address:No.53 , Yungu Road, Jiangyin City, Jiangsu Province, China.

5. Q: Can we order one set machine?

A:Yes, you can.

we are close to 20 years experienced manufacturer of scrap metal baler , scrap metal shear ,scrap metal cursher machine.

can offer good quality machine and excellent asfter sale service.

METAL BALER CHARACTERISTIC

1. The hydraulic driving is adopted for the machine

2. The manual or PLC automatic control operations.

3. Installation does not need the foundation screw

4. Can choose diesel engine drive or motor driv

5. Three out- bag ways: Turn, Side push, front push.

6. The chamber box size and bale size can according to the customer request.

7, Voltage/frequency can according to customer requirement.

8, Can add two sides of knives and teeth on the chamber box

9. Can be equipped with cooler or heater
